Waldorf Quantum MK2

Waldorf Quantum MK2 - Image n°1
Waldorf Quantum MK2 - Image n°2
Waldorf Quantum MK2 - Image n°3
Notre Prix4790,00€
Prix public
Tarif de livraison OFFERTE
Frais de ports OFFERTS
Garantie :
3 an(s)
Disponibilité :
Stock principalSous 7 jours
La livraison sous 7 jours signifie que le produit est en stock chez notre fournisseur.
Ajouter au panier

Waldorf Quantum MK2 - Image principale
Waldorf Quantum MK2 - Image n°2
Waldorf Quantum MK2 - Image n°3
Waldorf Quantum MK2 - Image n°4

Caractéristiques Quantum MK2

La technologie de synthétiseur légendaire du Waldorf Quantum – désormais dotée de nouvelles fonctionnalités.    Quantum MK2 a été mis à niveau avec un clavier aftertouch polyphonique de 61 touches de Fatar, un stockage d'échantillonnage augmenté à 59 Go, une conception mécanique et un affichage améliorés.
Le nouveau firmware 3.0 permet jusqu'à 16 numériques ou toute combinaison utilisant le filtre 8 analogiques avec 8 numériques supplémentaires



  • Hybrid Digital/Analog Polyphonic Synthesizer

  • 61 Keys high-quality Fatar TP/8SK keyboard, channel aftertouch

  • 8 voices with analog filter, up to 16 voices with digital filters

  • Dual timbral: split or layered mode with separate stereo audio outputs

  • 3 stereo digital oscillators each capable of five synthesis algorithms

  • Wavetable: Waldorf style with latest additions from Nave including speech synthesis, wavetable generation from audio and new features

  • Waveform: Waveform with up to 8 simultaneous waves per Oscillator in detuned or chordal mode with hard-sync, warp & PWM as well as tunable noise

  • Particle: Sampler in traditional and granular mode using multi-samples or live input

  • Resonator: Exciter using multi-sampling plus filter bank sound model.

  • New Kernel synthesis with possibilities from classic 6 operator FM to innovative audio rate wavetable modulations

  • Two analogue lowpass filters per voice each in 24 or 12 dB configuration using innovative link modes, or alternatively two digital multi-mode filters

  • Digital former: Additional digital algorithms per voice like comb filter, high-pass, band-pass & notch filters (Nave, Largo or PPG models), bit-crusher, drive and more

  • Flexible routing system for order of filters & digital former and individual oscillator routings

  • 6 LFOs in poly and global mode with extensive parameter set

  • 6 loopable envelopes

  • Komplex: multistage LFO/envelope modulator

  • Extensive modulation matrix with 40 slots and easy via-controller assignments

  • Intuitive modulation assignment via panel elements and control LEDs

  • Master effect rack of 5 slots for each timbre choosing from FX like phaser, flanger, chorus, reverb, drive, eq and more.

  • Compressor for main output

  • Step sequencer with step recording, parameter automation and scale-based pitch quantization

  • Microtonal pitch configurations capable of importing Skala scl files

  • Capable of polyphonic aftertouch via internal keybed or external MIDI inputs

  • Chord and latch buttons

  • Unisono mode

  • Module-based preset system for effects, oscillators, step-sequenzer and Komplex modulator

  • Single-function potentiometer and encoder controls for intuitive editing

  • Visualisation and deeper sound editing via context-sensitive high-resolution capacitive multi-touch display

  • Spectrum Analyzer and Oscilloscope at various processing stages

  • Up to 10,000 sound patch capacity organized by banks, attributes, author and patch number.

  • Favourites lists for quick recall of sound patches like for set-lists etc.

  • Pre-loaded with wide variety of patches by acclaimed sound designers

  • MIDI output of local keyboard, wheels and assignable panel elements

  • Automation of sound parameters from MIDI inputs via MIDI CC learn function

  • Recording of samples from audio inputs or self-recording of audio outputs

  • 4 GB*) internal Flash memory for presets and wavetables, 59GB internal sample storage

  • Pre-loaded with approx. 2 GB sample data

  • On board audio file editor

  • Export & import of presets, sample & wavetable via SD card or USB drive

  • Import of Nave presets and selected legacy FM .syx files

  • Mod wheel can be assigned to any parameter which can be modulated in the matrix or via quick assign

  • Pitch wheel can be assigned to each oscillator individually

Sampling capabilities Each of the 3 Oscillators of a single timbre can be used in one of three modes using samples:

  • Stereo Multi-Sampler with looping and reverse playback

  • Granular Sampler with extensive parameter set

  • Resonator model using sampler as exciter

  • Samples are organized using key and velocity maps, selections rules like round robin, random etc., and individual pitch, gain and pan settings.

  • Samples are stored in internal Flash memory of 59GB capacity pre-filled with 2GB specially made for Quantum factory samples.

  • New samples can be recorded from external stereo audio inputs, or from self-recording Quantums own engine.

  • Samples can also be imported an stored to internal Flash via SD card or USB drive using WAV and AIFF file format (44.1kHz sample rate).

  • The Quantum allows for a huge range of sample-based sound design capabilities from classical synths sounds to uncharted territories.

  • It’s worth noting that the sample use in the Quantum is always within a synthesizer’s sonic context, and it is not meant to work as a “bread and butter” sample keyboard to play back like traditional sampling instruments nor third party libraries.

Huge range of arpeggiator parameters:

  • 7 Algorithms to choose from like up, down, random etc.

  • Octave range

  • 7 Sort Orders

  • 3 Velocity Modes

  • Gate length

  • Swing

  • BPM

  • Beat Division

  • Rhythmic patterns

  • Reset Modes

  • Keyboard Latch chordal and non-chordal

If that’s not enough, individual patterns can be created in the step sequencer including transpositions and scale quantisations.


  • 2x stereo audio outputs for main and aux timbres

  • Stereo audio input for sample recording and real-time processing

  • High-Quality 24bit A/D and D/A converters

  • Headphone out with separate level adjustment

  • Sustain pedal input

  • Control pedal connector also capable of CV input (0-5V sensitivity)

  • USB host type A connector for interfacing MIDI controller or USB drives for sample/preset exchange and software updates

  • USB device type B connector for interfacing computer or other class-compliant MIDI USB hosts like iOS devices

  • SD Card for sample/preset exchange and software updates

  • DIN MIDI In, Out & Thru

  • Integrated power supply unit

Weight: 17.8 kg

Dimensions: 1.006 x 401 x 131 mm
