Size & weight : Instrument size : 325 x 390 x70 mm (12.79 x 15.35 x 2.76 inch)
Instrument weight : 4 kg (8.8 lbs)
Analog factory
MiniBrute Specifications :
Monophonic synthesizer
100% Analog Audio Signal Path
Steiner-Parker 2 pole Multimode Filter (Low Pass, Band Pass, High Pass and Notch)
Voltage Controlled Oscillator with Sub-Osc (Square, Sine, -1 & -2 oct)
Oscillator Mixer (Sub, Sawtooth, Square, Triangle, White Noise, Audio In)
Signal Enhancers :
Pulse Width Modulation
Ultrasaw generating shimmering sawtooth waveforms
Metalizer bringing extreme triangle harmonics
Brute Factor™ delivering saturation and rich harmonics
LFO1 with 6 waveforms (Sine, Triangle, Sawtooth, Square, Random Square, Random Sine) and bi-polar modulation destinations (to PWM & Metalize, Pitch, Filter, Amplifier)
LFO1 clock syncable to Arpeggiator (Arpeg, or free).
LFO2 with selectable rate and 3 vibrato modes (trill up, trill down, sine)
Two ADSR Envelope Generators with selectable slow/fast speed (from 1 millisecond to more than 10 seconds)
Keyboard Tracking on the VCF Cutoff
25 note semi-weighted keyboard with aftertouch (assignable to Cutoff or Vibrato amount)
Mod Wheel (assignable to Cutoff, Vibrato, or LFO amount)
Pitch Wheel (with selectable bend range)
Octave selector from -2 to +2 octaves
External Analog Audio Input
CV In/Out controls: Pitch, Filter, Amp
MIDI In/Out with 5 pin DIN connectors
USB MIDI In/Out
CV Gate source selector (Audio/Hold/Keyboard)
1/4” Audio Output and 1/4” Headphone Output
Full Function Arpeggiator:
4 modes of arpeggiation
4 octave range control
6 step divisions
6 Swing positions
Hold function
Tempo knob
Tap tempo
MIDI Sync
Rugged Aluminium enclosure
12V DC 1A power
