Organ Section
2 - VASE III as Digital Tone-wheels, Transistor Organ and Pipe Organ
61 polyphony (for manual, except Pipe Organ)
8 polyphony (for pedal, except Pipe Organ)
63 polyphony (maximum, on Pipe Organ)
Extra Voice Section
VASE III, 63 polyphony (maximum)
Keyboards : 2 x C1 to C6 61-key
Drawbars : 9 Pitches, assignable for Upper, Pedal, Lower
Manuals: 6 choices (B-Type1, B-Type2, Mellow, Vx, Farf, Pipe), valiable key-click,
Pedal: 4 choices (Normal, Muted, Synth1, Synth2), 5 choices key-click
Touch Response Percussion Buttons Second Harmonic, Third Harmonic, Fast Decay, Volume Soft
Adjustable Touch, Velocity, Decay (Fast, Slow), Level (Normal, Soft)
Extra Voice : Instruments 6 Groups (A. Piano, E. Piano, Keyboard, Wind, Other, Library) Upgradable via Library
Effects : Vibrato and Chorus , Digital Scanner , Buttons: 1, 2, Chorus, Upper On, Lower On , Overdrive Digital, 4 programs , Control: On, Amount
Multi Effects 8 programs for Organ/Extra Voice individually Control: On, Amount
Equalizer : for Organ: Bass, Mid (sweep), Treble, Tone for Extra Voice: Bass, Mid (sweep), Treble
Internal Leslie : Advanced Digital, 2 Rotors Buttons: Bypass, Stop, Fast
Reverb : Digital, 11 programs Control: On, Depth
Master Equalizer : Control: Bass, Mid Gain, Mid Frequency, Treble
Buttons : Lower to Pedal Octave Up, Octave Down, Lower, Transpose
Adjustable Coupler Highest note, Split Point
Capacity 100 User Patches, 100 Preset Patches, Manual
Favorites 10 buttons Patch Load Options
Drawbar Registrtion, Drawbar Parameters, Extra Voice, Internal Zone, External Zone, Organ Effects, Exv Effects, Reverb
Controllers Volumes Master Volume, Music Volume, Extra Voice Volume
Switch Power On/Off
Music Player File Format WAV (44.1kHz, 16bit, Stereo), MP3 (44.1kHz, 128kbps, Stereo)
Control Song, Play/Pause Storage USB Flash Drive
Display 20 - Characters, 2 - Lines 8 Control Buttons and Value knob
MIDI :Templates 5 Templates(SK2)
External Zones : 3 Zones, assignable any keyboards
Connections : MIDI In, Out Audio Line Out L, R, Headphones Leslie 8 - pin, 1 and 3 channels available Other Foot Switch, Damper Pedal, Exp. Pedal, DC IN (12V)
Dimensions : 37 1/4"(W) x 17 7/8"(D) x 6 3/4"(H)
Weight : 35 1/4 lb
