General

Sample Rates: 44.1, 48, 88.2, 96, 176.4, 192kHz from internal crystal or externally supplied clock (no sample rate conversion)
Bit Depths: 24 bit I/O, 32 bit processing
PCIe Specification:

- PCIe Base Specification 1.1 Compliant
- Form Factor: Universal-keyed PCIe x1 Card
- 3.3V I/O
- PCIe Bus-Mastering subsystem reduces CPU usage
E-MU E-DSP 32-bit DSP with 67-bit accumulator (double precision w/ 3 headroom bits)
Hardware-accelerated, 32-channel mixing, and multi-effects processing
Zero-latency direct hardware monitoring w/effects
ASIO2, WDM/MME/DirectSound, x64 Drivers
EDI (E-MU Digital Interface) proprietary 64-channel audio link over CAT-5 cable
Anti-Pop speaker protection minimizes noise during power on/off
Ultra-low jitter clock subsystem: < 1ns in PLL mode (44.1kHz, Opt. S/PDIF Sync)

Analog Line Inputs (4)

Type: servo-balanced, DC-coupled, low-noise input circuitry
A/D converter: AK5394A
Level (software selectable):

- Professional: +4dBu nominal, 20dBu max (balanced)
- Consumer: -10dBV nominal, 6dBV max (unbalanced)
Frequency Response (20Hz-20kHz): +0.0/-.03dB
Dynamic Range (1kHz, A-weighted): 120dB
Signal-to-Noise Ratio (A-weighted): 120dB
THD+N (1kHz at -1dBFS): -110dB (.0003%)
Stereo Crosstalk (1kHz at -1dBFS): < -120dB Analog Line Outputs (6)

Analog Line Outputs (6)

Type: balanced, AC-coupled, 2-pole low-pass differential filter
D/A converter: CS4398
Level (software selectable):

- Professional: +4dBu nominal, 20dBu max (balanced)
- Consumer: -10dBV nominal, 6dBV max (unbalanced)
Frequency Response (20Hz - 20kHz): 0.0/-.06dB
Dynamic Range (1kHz, A-weighted): 120dB
Signal-to-Noise Ratio (A-weighted): 120dB
THD+N (1kHz at -1dBFS): -105dB (.0006%)
Stereo Crosstalk (1kHz at -1dBFS): < -115dB

Combo Microphone Preamplifier/Hi-Z/Line Inputs (2)

Type: E-MU® XTC™ combo mic preamp and Hi-Z/line input w/ Soft Limiter
Gain Range: +60dB
Frequency Response (min gain, 20Hz-20kHz): +0.0/-0.1dB
Stereo Crosstalk (1kHz min gain, -1dBFS): < -125dB
Hi-Z Line Input:

- Input Impedance: 1Mohm
- Max Level: +18dBV (20.2dBu)
- Dynamic Range (A-weighted, 1kHz, min gain): 118dB
- Signal-to-Noise Ratio (A-weighted, min gain): 118dB
- THD+N (1kHz at -1dBFS, min gain): -105dB (.0006%)
Microphone Preamplifier:

- Input Impedance: 1.5Kohms
- Max Level: +6dBV (+8.2dBu)
- EIN (20Hz-20kHz, 150ohm, unweighted): -129.5dBu
- Signal-to-Noise Ratio (A-weighted, min gain): 119dB
- THD+N (1kHz at -1dBFS, min gain): -110dB (.0003%)
- Phantom Power: 48V
- Soft Limiter: 5dB max compression (software selectable)

Headphone Amplifier

Type: linear power amplifier
D/A converter: CS4398
Gain Range: 85dB
Maximum Output Power: 50mW
Output Impedance: 22ohms
Frequency Response (20Hz-20kHz): +0.0/-0.07dB
Dynamic Range (A-weighted): 118.5dB
Signal-to-Noise Ratio (A-weighted): 118dB
THD+N (1kHz, max gain): 600ohm load: -96dB
Stereo Crosstalk (1kHz at -1dBFS, 600 ohm load): < -100dB

Phono Input (stereo)

Type: RIAA equalized phono input
Maximum level:

- Professional: 60mV RMS
- Consumer: 15mV RMS
Input Impedance: 47Kohm
Frequency Response (20Hz - 20kHz): +0.1/-0.3dB
Dynamic Range (A-weighted): 96dB
Signal-to-Noise Ratio (15mV RMS unbal input, A-weighted): 96dB
THD+N (1kHz, 15mV RMS input): -90dB (.003%)
Stereo Crosstalk (1kHz at -1dBFS): < -80dB

Digital I/O

S/PDIF:

- 2 in/2 out coaxial (transformer coupled)
- 2 in/2 out optical (software switched with ADAT)
- AES/EBU or S/PDIF format (software selectable)
ADAT:

- 8 channels, 24-bit @ 44.1/48kHz
- 4 channels, 24-bit @ 88.2/96kHz (S-MUX compatible)
- 2 channels, 24-bit @ 176.4/192kHz
MIDI

- 2 in, 2 out

Synchronization

Internal crystal sync at 44.1, 48, 88.2, 96, 176.4, 192kHz
External sample rate sync via

- ADAT (44.1 - 192kHz)
- Optical S/PDIF (44.1 - 96kHz)
- Coaxial S/PDIF (44.1 - 192kHz)

Retail Box Contents

E-MU 1010 PCIe Card
E-MU MicroDock M
EDI (E-MU Digital Interface) cable (3 meters)
Universal power adapter
MIDI breakout cable
Quick Start installation guide
E-MU Digital Audio System CD-ROM

- Microsoft® Windows® XP, XP x64, Windows Vista®, Vista x64 Drivers
- E-MU PatchMix DSP
- E-MU Power FX (Windows XP only)
- E-MU E-DSP Effects Library - Owner's Manual and Tutorials
E-MU Production Tools Software Bundle

- Cakewalk SONAR LE 6.3
- Steinberg Cubase 4 LE
- Ableton Live Lite 6 E-MU Edition

- IK Multimedia AmpliTube LE
- IK Multimedia T-RackS EQ
- Celemony Melodyne essential
- Waldorf Attack, Waldorf D-Pole
- Waldorf PPG Wave
- SFX Machine LT
- Creative EAX® ADVANCED HD™ ALchemy (Vista only)
- E-MU Proteus VX

Minimum System Requirements

Intel® or AMD® processor - 1 GHz or faster
Intel, AMD or 100% compatible motherboard & chipset
Microsoft® Windows® XP (SP 3), Windows XP x64, Windows Vista® (SP1 or higher), Vista x64
256MB System RAM
900MB of free hard disk space for full installation
PCIe x1 Compliant slot for E-MU 1010 PCIe card (also compatible with x4, x8 or x16 PCIe slots)
CD-ROM/CD-RW or DVD-ROM drive required for software installation
XVGA Video (1024 X 768)
